63.5 MM Square Shape Metal Speed Clips For Fixing Insulaton Metal Nails

Name: 635 MM Square Shape Metal Speed Clips For Fixing Insulaton Metal Nails
Brand: HUIHAOCUSTOM
Price: 1 USD

Quality 63.5 MM Square Shape Metal Speed Clips For Fixing Insulaton Metal Nails for sale

Brand Name : HUIHAOCUSTOM

Model Number : Square speed clips

Certification : ISO9001-2015

Place of Origin : CHINA

MOQ : 10000 pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 50000 pcs per hour

Delivery Time : 10 work days

Packaging Details : 500 pcs per pp bags. 10 bags per carton

NAME : Square speed clips , self locking washers

Material : Galvanized Steel, Stainless steel , aluminum

Diameter : 63.5x63.5mm or customized

Shape : Square shape

Thickness : 0.5mm or customized thickness

Hole size : according the nail dia to fix

Usage : Fixing Insulation Pins

Samples : Supported

Contact Now

63.5 MM Square Shape Metal Speed Clips For Fixing Insulaton Metal Nails

Quick details of the Square Speed Clips

Name :Square speed clips , also named square self locking washers. square speedfix clips
Material: Stainless steel in common . also could be mild steel or aluminum alloy.
Thickness of the material:0.4mm-1.0mm, 0.4mm & 0.5mm in common
Shape : square shape
Size : 30mm,32mm,40mm, 50mm,63.5mm in common
Hole size :0.105'', due to the fixing pins diameter.
Features: Enough hard; firm locking; no burr and smooth
Surface treatment: Polished finished for stainless steel material washer, zinc coated for mild steel material, UV coated for aluminum.

Name: 2.5" Galvanized Steel Square Self Locking Washers

Material: Galvanized Steel, Stainless Steel , Aluminum

Size: 2-1/2" x 2-1/2" (63.5mm x 63.5mm),30mm,40mm,50mm etc

Thickness: 0.5mm

To Fix: 1. perforated base insulation pins

2. self adhesive insulation pins

3. metal lacing anchors

4. CD weld pins

5. Bi-metallic pins

63.5 MM Square Shape Metal Speed Clips For Fixing Insulaton Metal Nails

Ref photos of the Square Speed Clips

Specifications of the types of the metal speed clips

Name: Square speed clips

Material: Galvanized steel or stainless steel or aluminum

Thickness: 0.4mm, 0.5mm, 0.6mm

Diameter: 29x31mm, 32mm, 50mm, 63.5mm etc.

Name: Round Speed Clips

Material: Galvanized steel or stainless steel or aluminum

Thickness: 0.4mm, 0.5mm, 0.6mm

Diameter: 20mm, 25mm, 30mm, 32mm, 35mm, 38mm, 50mm etc.

Name: Dome cap self locking washers

Material: Galvanized steel or stainless steel or aluminum

Thickness: 0.4mm, 0.5mm, 0.6mm

Diameter: 22mm, 27mm, 30mm, 32mm, 38mm, 40mm, 50mm etc.

Application of the Square Speed Clips

1. Simply press the self-locking washer onto the pin up to the insulation until the desired

position is reached.

2. Then clip off, (or bend over) the remaining portion of pin for a permanent attachment.

3. Both Round or Square self-locking washers are available as a matter of design or application

preference.

4. The domed, multi-lanced hole design provides for ease of locating washer on pin and positive

locking.

5. Most styles of washers are manufactured with a beveled edge to prevent the washer from

cutting into the insulation facing.

FAQ Of Xiangyi Metal Product Co.,Ltd

1. Are you a manufacture or a trader?

We are a manufacture, located in Hebei province, China.

2. Do you support product customization?
Yes, the material, the surface finish, the thickness, the center hole size all could be customized.

3. Can i get samples?
Yes, samples for quality confirm are supported in our company.

4. How do you control and ensure product quality?

1) Confirm with you every details before quoting.

2) Before production, we will reconfirm all the details again.
3) During production, we strictly implement "IATF 16949 Quality Management System" standard.

4) We will send you videos and pictures during the production and shipment process.

5. Advantage Of Xiangyi Parts

Cooperate with us, we can ensure:

1) Competitive price: we sale what we manufacture.

2) On-time delivery: we have the auto-production line to ensure the on-time delivery.

3) Excellent quality: we have rich experience for the cd weld pins, our products are in line with

international standard.

4) Good after-sale service: we offer good after-sale service for each order.
